It is mainly used in laboratory test for polymer materials mixing, warming sheeting, plasticzing ,ect and has features such as easy operation, small size , low noise and high safety.
|
规格/型号 Specification/type |
XK-160 | XK-200 | |
|---|---|---|---|
|
辊筒直径(mm) Roll diameter |
160 | 200 | |
|
辊筒工作长度(mm) Roll working length |
320 | 500 | |
|
前辊线速度(m/min) Front roll linear speed |
8.95 | 11.09 | |
|
辊筒速比 Roll friction ratio |
1:1.35 | 1:1.22 | |
|
一次投料量(kg) Batch capacity |
1-2 | 8-10 | |
|
电机功率(kw) Motor power |
5.5 | 11 | |
|
辊距(mm) Max.nip |
4.5 | 5 | |
|
外形尺寸(mm) Overall dimension |
长(L) | 1120 | 2082 |
| 宽(W) | 920 | 900 | |
| 高(H) | 1295 | 1150 | |
|
重量(t) Weight |
1.1 | 2.5 | |
